circles

FLUIDSEAL

ApplicationCleanroom supply- and return air, cleanbench filters
TypeEPA-HEPA and ULPA panel with a FluidSeal for 100% air tightness
MediaWaterproof micro glass fibers
Gasket2 Component polyurethane gel
SeparatorThermoplastic hotmelt
FrameExtruded anodized alumunium
FaceguardMild steel epoxy coated
FLUIDSEAL

FLUIDSEAL

TripleAir Technology maintains a policy of continuous product research and improvement, and retains the right to change product specification and design without notice.
© 2013.01 TAT

Technical Data
Style codeDimensions (WxHxD) mmFilter classification EN1822Nominal air flow (m/s)Air volume (m³/hr)Initial pressure drop (Pa)
TA-2-FS-14-G2-F3610x610x80H140.45600120
TA-2-FS-14-G2-F3610x762x80H140.45750120
TA-2-FS-14-G2-F3610x915x80H140.45900120
TA-2-FS-14-G2-F3610x1220x80H140.451200120
TA-2-FS-14-G2-F3610x1524x80H140.451500120
TA-2-FS-14-G2-F3610x1830x80H140.451800120
TA-3-FS-14-G2-F3610x610x104H140.4560085
TA-3-FS-14-G2-F3610x762x104H140.4575085
TA-3-FS-14-G2-F3610x1220x104H140.45120085
TA-3-FS-14-G2-F3610x1524x104H140.45150085
TA-3-FS-14-G2-F3610x1830x104H140.45180085
TA-4-FS-14-G2-F3610x610x128H140.4560070
TA-4-FS-14-G2-F3610x762x128H140.4575070
TA-4-FS-14-G2-F3610x1220x128H140.45120070
TA-4-FS-14-G2-F3610x1524x128H140.45150070
TA-4-FS-14-G2-F3610x1830x128H140.45180070
